Air / Gas tanks

  • serbatoi gas 1
  • serbatoi gas 2
  • serbatoi gas 3

PNEUMOIDRAULICA ENGINEERING designs and supply many kinds of tanks for compressed air and gas. The standard range is accompanied by the special “tailor-made” perfectly answering to the customer’s technical specification. Numerous are the fields of application: Oil & Gas, chemical, pharmaceutical, industrial, etc.

Standard features:

  • Media: compressed air or nitrogen
  • Max. working pressure: 12 bar
  • Material: varnished carbon steel RAL 5015
  • Vertical or horizontal lay-out
  • Capacity up to 3.000 litres
  • Certification: CE87/404 – 2014/68/UE (PED)

Special features:

  • Madia: flammable gases
  • Working pressure over 12 bar
  • Material: stainless steel AISI 304 / AISI 316
  • Capacity up to 10.000 litres
  • ASME VIII div.1 “U” stamp
  • Executions suitable for potentially explosive areas (ATEX)
  • Installation in severe climate conditions (very low/very high temperatures, desert zones, etc.)
  • Special treatments (hot-dip galvanizing, specific paintings)
  • Testing Officiated and Certification on customer request
  • Tanks fully equipped (safety valve, pressure gauge, interception valve, stair, etc.)
  • Structural elements in accordance with UNI EN-1090
